POWER RECEPTACLE TYPE A/TYPE C 4.8A

POWER RECEPTACLE TYPE A/TYPE C 4.8A

BAA-015

DOWNLOAD FILES

SPEC

View full details
Product Information
Overview

Smart System: Built-in smart chip recognizes the individual device’s charging requirement to optimize the charge.
Safety: Fireproof housing and high-quality components for long service life. Unique 2 USB Ports: Charges two USB devices without adapters.
Tamper resistant(TR):TR design increases the electrical safety level by preventing the attempting to insert objects in to the outlet or open the plate.

Specifications
Size

105*43*45mm

Color

Cover: White (Customizable)

Base: Black (Customizable)

Enclosure

PC

Terminal

Copper Alloy | Acid Pickling



Mounting Yoke

Zinc Plated Steel

Weight

111g

Certification

culus

Standards

UL 498&CSA C22.2 No. 42-10

Receptacle Rating

15A/125Vac/60hZ

USB Rating

5 VDC/4.8A

Dielectric Voltage Withstand

1.25KV/1min

Flame Class

UL-94 V2

Wire

12-14 AWG
