Product Information
Overview
Smart System: Built-in smart chip recognizes the individual device’s charging requirement to optimize the charge.
Safety: Fireproof housing and high-quality components for long service life. Unique 2 USB Ports: Charges two USB devices without adapters.
Tamper resistant(TR):TR design increases the electrical safety level by preventing the attempting to insert objects in to the outlet or open the plate.
Specifications
Size |
105*43*45mm |
Color |
Cover: White (Customizable) Base: Black (Customizable) |
Enclosure |
PC |
Terminal |
Copper Alloy | Acid Pickling
|
Mounting Yoke |
Zinc Plated Steel |
Weight |
111g |
Certification |
culus |
Standards |
UL 498&CSA C22.2 No. 42-10 |
Receptacle Rating |
15A/125Vac/60hZ |
USB Rating |
5 VDC/4.8A |
Dielectric Voltage Withstand |
1.25KV/1min |
Flame Class |
UL-94 V2 |
Wire |
12-14 AWG |
